Portable Vinyl Hot Air Welding Machine With Adjustable Temperature / Fan Motor Speed

    Buy cheap Portable Vinyl Hot Air Welding Machine With Adjustable Temperature / Fan Motor Speed from wholesalers

    Buy cheap Portable Vinyl Hot Air Welding Machine With Adjustable Temperature / Fan Motor Speed from wholesalers
    • Buy cheap Portable Vinyl Hot Air Welding Machine With Adjustable Temperature / Fan Motor Speed from wholesalers

    Portable Vinyl Hot Air Welding Machine With Adjustable Temperature / Fan Motor Speed

    Ask Lasest Price
    Brand Name : MingYang
    Model Number : MY-BW-A
    Certification : CE
    Price : indeterminate
    Payment Terms : Western Union, MoneyGram, T/T,Paypal
    Supply Ability : 9889 sets / month
    Delivery Time : 2-5 working days
    • Product Details
    • Company Profile

    Portable Vinyl Hot Air Welding Machine With Adjustable Temperature / Fan Motor Speed

    110V / 220V PVC Profile Welding Machine / Flex Tent Welding


    Machine / HF Banner Welding Machine


    Product Description :


    ►Use for weld PVC, PE and other material can be hot melt, like flex, PVC cloth , etc


    ►No need glue, use hot air to weld


    ►Temperature, speed, fan motor speed are adjustable


    ►Welder nozzle has a sensor, can make the true temperature accurately


    ►High welding quality



    Main technical details :



    ►Machine name: Flex Banner Welding Machine

    ►Rated voltage: AC110-220V

    ►Frequency: 50-60HZ

    ►Power: 1000-3000W

    ►Temperature scope: 0-500℃

    ►Speed scope: 3-15m/min

    ►Dimension: 41*25*20cm

    ►Weight: 15kg

    ►Splicing width: 20-40mm

    ►Welding Thickness: 0.22-2mm

    ►Welding type: Automatic

    ►Welder cable: 10 meters

    ►Welder wheel: Aluminum wheel



    Operation Step :


    step 1

    Before hemming or welding, leave 30-40mm wide overlap edge for connection the two disjunct surface pieces, immobilize both ends of each disjunct pieces with something such as stick belt or clamp

    step 2

    Turn on the power, according to quality and thickness of the PVC banner, consider the ground circumstance, set the proper termperature and speed, adjust the suitable hot-air blowing rate, wait for machine hot up around 2 minutes

    step 3

    Bring up the machine, place the rubber wheel at the end of the overlap edge

    step 4

    Turn the handle to left down, insert the welder nozzle into the gap of two overlap pieces, then the machine will moving and seaming automatic

    step 5

    During welding, use the gripe to align the moving direction, let the upper piece edge be in touch with the inner side of the welder nozzle

    step 6

    After the machine go pass the overlap edge to the end, the two disjunct pieces will be joined together, then turn the welder handle to right, it will stop moving

    step 7

    Turn off the heater switch, wait the gun come to cold, then turn off the power supply is ok


    Notice:


    ►To prolong the electrothermal heater, after work it is strongly advice that cooling the heater at first, then turn off the power 5 minutes later. In case of the power suddenly be off, should handle the welding gun away firstly, and close down the temperature knob, nextly consider the problem of power supply.


    ►To get better satisfied bonding effect, the ground of the overlap pieces should be smoothly, hard and heat resistive. We suggest that the operator may do some more test and practice using some samples of the pieces to get the suitable speed and temperature and hot-air blowing rate before operate it for seaming formally


    Any Questions Or Demand Please Send Your Inquiry Details At The Below , Thank You :-)
