Adjustable Vinyl Banner Welding Machine Automatic With 480320330 Mm Dimension

Automatic Low Cost Hot Air Vinyl Flex Banner Welding

Machine / Air Welder Machine

Advantage of Banner Welding Machine :

►No need glue, Just use hot air to welding materials , low cost

►Welding Temperature, speed, fan motor speed are adjustable

►Welder nozzle has a sensor, can make the true temperature accurately

►High welding quality and efficient .

►Easy to operation and good welding effect

Main technical details of Banner Welding Machine :

►Machine name: Vinyl Flex Banner Welding Machine / Automatic Hot Air Welder Machine

►Warranty: One year

►MOQ: One set of banner welding machine

►Rated voltage: 110V / 240 V

►Frequency: 50-60 HZ

►Power: 1600 W

►Temperature scope:10-500℃

►Speed scope: 5-15m/min

►Dimension: 480*320*330 mm

►Weight: 10 kg

►Splicing width: 2-4 cm

►Welding Thickness: 0.22-2 mm

►Welder wire: 10 meters (the longest)

►Welder wheel: Aluminum wheel

Operation Step of Banner Welding Machine :

step 1	Before hemming or welding, leave 30-40mm wide overlap edge for connection the two disjunct surface pieces, immobilize both ends of each disjunct pieces with something such as stick belt or clamp
step 2	Turn on the power, according to quality and thickness of the PVC banner, consider the ground circumstance, set the proper termperature and speed, adjust the suitable hot-air blowing rate, wait for machine hot up around 2 minutes
step 3	Bring up the machine, place the rubber wheel at the end of the overlap edge
step 4	Turn the handle to left down, insert the welder nozzle into the gap of two overlap pieces, then the machine will moving and seaming automatic
step 5	During welding, use the gripe to align the moving direction, let the upper piece edge be in touch with the inner side of the welder nozzle
step 6	After the machine go pass the overlap edge to the end, the two disjunct pieces will be joined together, then turn the welder handle to right, it will stop moving
step 7	Turn off the heater switch, wait the gun come to cold, then turn off the power supply is ok

Notice of Banner Welding Machine :

►To prolong the electrothermal heater, after work it is strongly advice that cooling the heater at first, then turn off the power 5 minutes later. In case of the power suddenly be off, should handle the welding gun away firstly, and close down the temperature knob, nextly consider the problem of power supply.

►To get better satisfied bonding effect, the ground of the overlap pieces should be smoothly, hard and heat resistive. We suggest that the operator may do some more test and practice using some samples of the pieces to get the suitable speed and temperature and hot-air blowing rate before operate it for seaming formally

FAQ :

1. Q : What's the Function ?

A : The Function is : Welding PVC / Flex Banner , Plastic and other materials can be hot melt .

2. Q : What's the MOQ ?

A : The MOQ is one set of Welding Machine .

3. Q : Is it automatic welding ?

A : yes , It is automatic welding banner .

4. Q : How long is the warranty period ?

A : The warranty is 12 months .

5. Q : How can i pay ?

A : Our company accept : T/T , Western union , Paypal .

6. Q : What time will delivery the Banner welding machine after payment ?

A : We will delivery the Banner welding machine in 3-5 working days after you payment .
